◆技巧參數 Main technical parameters (請向下瀏覽器大有量的例子照片頭像供參閱)
器機型號 Model |
STR-9070/9080 |
STR-1010 |
工作中艙盡寸 Internal size(mm) |
900×800×650 |
1000×1000×790 |
服務器厚度 Complete machine size(mm) |
900×1030×1750 |
1000×1540×1830 |
電源模塊 Power |
220V 50Hz |
220V 50Hz |
廣州POS機戶外照指路明燈 Machine floodlight |
一個60W防火燈 |
220V 13W發展節能環保燈 |
滾桶承受 Roller bearing |
10-30Kg |
10-30Kg |
分離處理器交流接觸器 Separator motor |
220V 50Hz 550W |
220V 50Hz 550W |
分離處理器風速 Separator air volume |
8.5m3/min |
8.5m3/min |
減少大氣源 Compressed air source |
2-8bar(kg/cm2) |
2-8bar(kg/cm2) |
機氣含水量 Weight |
320kg |
380 kg |
◆企業產品特別 Product features
1. 設汁新鮮、漂亮大膽、結構特征科學研究、操作步驟非常方便;
2. 自己的控制自己噴砂,具有定時開關噴砂,點動標記等功能鍵;
3. 輥筒外徑及噴槍的數量可會根據業主實際需求開發打造;
4. 就行了手動操作時,又可自動的,噴砂的質量好,一機常用。
1.novel design, beautiful and easy, scientific structure, convenient operation
2.Automatic control automatic gush arenaceous, have the point start timing gush arenaceous, positioning, and other functions;
3.Roller diameter and spray gun quantity can be designed according to the customer demand;
4.Can manual and automatic, gush arenaceous well, multi-use.
◆應用超范圍 Applicable scope
可用于廣泛小鏜孔的一鍵或自行噴砂,假如:電廚衛電器品、鏍絲、塑料板材制
品、鈕扣、拉鏈頭、亞克力、機氣零構件等;
Apply to lots of small the manual or automatic spray sand, for example: electric wood products, screw, plastic products, button, zipper, the force that press a gram, machine parts, etc.
